SERVO CONTROLLERS

OACIS-2X is capable to integrate and expand your servo system with abundant input & output channels. And it has been proven against high durability and reliability for long time. We also supply more simpler servo controller, OACIS-1X. It is helpful to choose OACIS as your servo system without cost burden.
Lately we released OACIS-2XC for industrial network. We have good hopes that its compact size and competitive price satisfy your requirement. Please compare specification of them against each other. You can also see various system examples about OACIS-2X(C) and OACIS-1X(C).


DIGITAL INPUTS & OUTPUTS (PNP/NPN)

SERVO CONTROLLERS OACIS-2x

OACIS-2X

OACIS-1x

OACIS-1X

OACIS-2XC

OACIS-2XC

OACIS-1XC

OACIS-1XC

Ethernet_IP_PROFINET_CC-LINK X
(Hardwired)
X
(Hardwired)
1 Port
(via Industrial Network)
1 Port
(via Industrial Network)
AXES QUANTITY 2 1 2 1
SYSTEM INPUTS Program Start, Program Stop, Return Home, Reset, E-Stop
SYSTEM OUTPUTS Home OK, Program Home OK, Ready, Error, Program End
STATUS BIN 4 Bit 4 Bit 5 Bit 5 Bit
SET PROGRAM IN 7 Ch 7 Ch 7 Ch 7 Ch
OUT 7 Ch 7 Ch 7 Ch 7 Ch
PROGRAMMABLE INPUT 14 Ch 6 Ch 14 Ch 14 Ch
OUTPUT 14 Ch 5 Ch 14 Ch 14 Ch

COMMUNICATION PORTS

ETHERNET 1 Port 1 Port 1 Port 1 Port
RS422 2 Port X X X
RS232 2 Port 2 Port 2 Port 2 Port

SIGNAL INPUTS

ANALOG INPUTS 4-20mA 6 Ch 2 Ch 6 Ch
(4Ch: +/-10V, 2Ch: Selectable)
X
+/- 10V 2 Ch
ENCODER INPUTS
TTL 2 Ch 1 Ch X X
LINE DRIVER 2 Ch 2 Ch

DATA

PROGRAM STEPS Max 700 Steps
PROGRAM QUANTITY Max 120 Programs
DATA STORAGE CAPA Min 1 Million Cycles

DIMENSION AND WEIGHT
